Mascot
Mascot 8660 100W 12V/24V Switch mode DC/DC converter with electrical separation, unregulated output
Product code: PDL18660122400
Electrically Isolated
£144.87Excl. VAT, per unit£173.84 Inc. VAT
In stock
Min order 1 · Suitable for new designs
UK shipping £8.00 Inc. VATFlat rate to mainland UK and Northern Ireland (~0.00 kg). Channel Islands, Isle of Man, Republic of Ireland and international orders need a shipping quote.
Ordering 5+ units? Volume discounts available.
- 1-year manufacturer warranty
- Technical support: 01189 795319
Description
A Switch mode DC/DC converter with an unregulated output, the input electrically separated from the output and Maximum power of 100W with the input protected against reverse Polarity and the output with overvoltage, short circuit and thermal protection. The converter is CE and E marked.
Product Specification
- Ce E Marked
- CE and E Marked
- Continuous Load Current
- 4A
- Electrical Separation
- Yes
- Input Terminals Conv
- 6.3mm Push on
- Input Voltage Conv Dc
- 12 VDC
- Input Voltage
- 10-16 VDC
- Maximum Power
- 100W
- Maximum Power Range
- 100W
- Model
- 8660
- MPN
- 8660122400
- Output Terminals
- 6.3mm Push on
- Output Voltage Text
- 24V DC
- Output Volt Conv Dc
- 24V DC
- Power Type
- Switch Mode
- Regulated Output
- Unregulated
- Weight
- 1Kg
Tested & certified to industry standards
