What is a DC/DC converter?

A DC/DC converter is an electronic circuit that changes one DC voltage into a different regulated DC voltage — either stepping down (buck), stepping up (boost) or holding output fixed across a wide input range.

24V to 12V converter — what should I look for?

Match the continuous amps to your accessory load, confirm the input window covers 21–30V (nominal 24V system with charging), and choose an isolated model if the 12V accessories share a chassis ground with sensitive electronics.

Isolated vs non-isolated DC/DC — which do I need?

Isolated converters are safer for multi-source or ground-referenced systems and eliminate ground loops in audio, measurement and telecoms. Non-isolated buck/boost converters are smaller and cheaper for a single-battery vehicle or off-grid install.

How efficient are your DC/DC converters?

Professional Mascot DC/DC converters typically run at 88–94% efficiency at full load, with clean current-limit and short-circuit protection as standard.

DC/DC Converters

Mascot DC/DC converters for industrial, transport, marine, telecoms and mobile equipment where the source is a battery or vehicle supply rather than the mains. The range Converts standard nominal inputs (12 V, 24 V, 48 V) to regulated DC outputs from 5 V up to 48 V, with rated power from a few watts up to several hundred watts. Wide input windows tolerate real-world supply variation, cold-crank dips and load-dump transients. Key features • High-efficiency switch-mode topologies • Low quiescent current • Isolated or non-isolated outputs depending on the part Built-in protection • Reverse polarity • Input under- and over-voltage • Output short-circuit • Over-current • Over-temperature Compliance Most models are CE and UKCA marked and qualified to the relevant EMC, safety and (where applicable) E-mark / railway standards for in-vehicle use. Mechanical formats Open-frame PCB modules, chassis-mount enclosures and DIN-rail housings, with screw terminals or industry-standard DC connectors to simplify integration. UK distribution & custom options Pulsar Developments distributes the full Mascot DC/DC range in the UK. For non-standard input or output voltages, higher isolation, conformal coating or ruggedised enclosures, our engineering team can quote a bespoke design — call us on 01189 795319 or fill in our online form.

57 of 57 products

DC/DC converters — 12V, 24V and 48V step-up / step-down

A DC/DC converter takes one DC input voltage and produces a different, regulated DC output — stepping 24V vehicle systems down to 12V accessory rails, boosting 12V battery banks to 24V or 48V loads, or providing isolated auxiliary supplies for control electronics on high-voltage buses.

Pulsar Developments supplies UK-stocked Mascot DC/DC converters from 5W through 200W+, covering vehicle, marine, broadcast, telecoms and industrial applications. Standard input windows cover 9–18V, 18–36V and 36–75V nominal buses; output voltages range from 3.3V logic through 48V PoE injectors.

What to look for

Isolated vs non-isolated. Isolated converters break the ground reference between input and output — needed for safety, ground-loop elimination and multi-source systems. Non-isolated (buck/boost) are smaller and cheaper for single-battery installs.
Input voltage window. Match the converter's minimum input voltage to your battery's end-of-discharge voltage, and its maximum to the fully-charged / alternator-boosted voltage.
Continuous output current. Rate the converter for the continuous DC amps your load draws at the output voltage, plus 20% headroom for thermal derating.
Efficiency and cooling. Higher-efficiency converters run cooler in enclosed installs — 88–94% is typical for a well-specified professional DC/DC.

Frequently asked questions

What is a DC/DC converter?: A DC/DC converter is an electronic circuit that changes one DC voltage into a different regulated DC voltage — either stepping down (buck), stepping up (boost) or holding output fixed across a wide input range.
24V to 12V converter — what should I look for?: Match the continuous amps to your accessory load, confirm the input window covers 21–30V (nominal 24V system with charging), and choose an isolated model if the 12V accessories share a chassis ground with sensitive electronics.
Isolated vs non-isolated DC/DC — which do I need?: Isolated converters are safer for multi-source or ground-referenced systems and eliminate ground loops in audio, measurement and telecoms. Non-isolated buck/boost converters are smaller and cheaper for a single-battery vehicle or off-grid install.
How efficient are your DC/DC converters?: Professional Mascot DC/DC converters typically run at 88–94% efficiency at full load, with clean current-limit and short-circuit protection as standard.

DC/DC Converters

Mascot 5060 41W 18-32V/13.6V Switch mode DC/DC converter with a Regulated output

Mascot 8660 100W 12V/12V Switch mode DC/DC converter with electrical separation, unregulated output

Mascot 8660 100W 12V/24V Switch mode DC/DC converter with electrical separation, unregulated output

Mascot 8661 160W 24V/12V Switch mode DC/DC converter with electrical separation, Unregulated output

Mascot 8662 80W 24V/13.5V Linear DC/DC converter with regulated output

Mascot 8860 75W 24V/13.3V Switch mode DC/DC converter with a Regulated output

Mascot 8861 81W 24V/12V Switch mode DC/DC converter with electrical separation, unregulated output

Mascot 8861 81W 24V/24V Switch mode DC/DC converter with electrical separation, unregulated output

Mascot 8861 81W 24V/48V Switch mode DC/DC converter with electrical separation, unregulated output

Mascot 8861 81W 48V/12V Switch mode DC/DC converter with electrical separation, unregulated output

Mascot 8861 81W 48V/24V Switch mode DC/DC converter with electrical separation, unregulated output

Mascot 8862 81W 12V/13.5V Switch mode DC/DC converter with electrical separation and Regulated output

Mascot 8862 81W 12V/24V Switch mode DC/DC converter with electrical separation and Regulated output

Mascot 8862 81W 12V/48V Switch mode DC/DC converter with electrical separation and Regulated output

Mascot 8862 81W 24V/13.2V Switch mode DC/DC converter with electrical separation and Regulated output

Mascot 8862 81W 24V/24V Switch mode DC/DC converter with electrical separation and Regulated output

Mascot 8862 81W 24V/36V Switch mode DC/DC converter with electrical separation and Regulated output

Mascot 8862 81W 24V/48V Switch mode DC/DC converter with electrical separation and Regulated output

Mascot 8862 81W 36V/13.2V Switch mode DC/DC converter with electrical separation and Regulated output

Mascot 8862 81W 36V/24V Switch mode DC/DC converter with electrical separation and Regulated output

Mascot 8862 81W 48V/13.2V Switch mode DC/DC converter with electrical separation and Regulated output

Mascot 8862 81W 48V/24V Switch mode DC/DC converter with electrical separation and Regulated output

Mascot 8862 81W 48V/48V Switch mode DC/DC converter with electrical separation and Regulated output

Mascot 8862 81W 80V/13.2V Switch mode DC/DC converter with electrical separation and Regulated output

Mascot 8862 81W 80V/24V Switch mode DC/DC converter with electrical separation and Regulated output

Mascot 9061 27W 12V/5V Linear DC/DC Converter with regulated output

Mascot 9061 27W 12V/6V Linear DC/DC Converter with regulated output

Mascot 9061 27W 12V/7.5V Linear DC/DC Converter with regulated output

Mascot 9061 27W 12V/9VLinear DC/DC Converter with regulated output

Mascot 9061 27W 24V/13.5V Linear DC/DC Converter with regulated output

Mascot 9061 27W 24V/6VLinear DC/DC Converter with regulated output

Mascot 9061 27W 24V/9V Linear DC/DC Converter with regulated output

Mascot 9061 27W Linear 24V/7.5V DC/DC Converter with regulated output

Mascot 9062 40W 24V/13.5V Linear DC/DC converter with regulated output

Mascot 9063 40W 24V/13.5V Linear DC/DC converter with regulated output with Backup

Mascot 9260 158W 24V/11.5-14.5V Switch mode DC/DC converter with electrical separation and Regulated output

Mascot 9260 168W 24V/20-29V Nom.Switch mode DC/DC converter with electrical separation and Regulated output

Mascot 9260 168W 36V/20-29V Switch mode DC/DC converter with electrical separation and Regulated output

Mascot 9260 168W 48V/11.5-14.5V Switch mode DC/DC converter with electrical separation and Regulated output

Mascot 9260 168W 48V/20-29V Switch mode DC/DC converter with electrical separation and Regulated output

Mascot 9260 168W 80V/20-29V Switch mode DC/DC converter with electrical separation and Regulated output

Mascot 9260 79W 10-32V/11.5-14.5V Switch mode DC/DC converter with electrical separation and Regulated output

Mascot 9261 110W 24V/13.5V Linear DC/DC converter with regulated output

Mascot 9262 81W 24V/13.2V Switch mode DC/DC converter with electrical separation and Regulated output

Mascot 9262 81W 24V/24V Switch mode DC/DC converter with electrical separation and Regulated output

Mascot 9262 81W 48V/13.2V Switch mode DC/DC converter with electrical separation and Regulated output

Mascot 9262 81W 48V/24V Switch mode DC/DC converter with electrical separation and Regulated output

Mascot 9262 81W 72V/13.2V Switch mode DC/DC converter with electrical separation and Regulated output

Mascot 9262 81W 72V/24V Switch mode DC/DC converter with electrical separation and Regulated output

Mascot 9262 81W 80V/13.2V Switch mode DC/DC converter with electrical separation and Regulated output

Mascot 9262 81W 80V/24V Switch mode DC/DC converter with electrical separation and Regulated output

Mascot 9460 106W 24V/13.2V Switch mode DC/DC converter with a Regulated output

Mascot 9660 158W 48V/11.5-14.5V Switch mode DC/DC converter with electrical separation and Regulated output

Mascot 9660 158W 80V/11.5-14.5V Switch mode DC/DC converter with electrical separation and Regulated output

Mascot 9660 168W 48V/20-28V Switch mode DC/DC converter with electrical separation and Regulated output

Mascot 9660 168W 80V/ 20-28V Switch mode DC/DC converter with electrical separation and Regulated output

Mascot 9970 276W 24V/13.8V Switch mode DC/DC converter with a Regulated output
