Mascot
Mascot 9061 27W 12V/6V Linear DC/DC Converter with regulated output
Product code: PDL19061120600
£35.80Excl. VAT, per unit£42.96 Inc. VAT
In stock
Min order 1 · Suitable for new designs
UK shipping £8.00 Inc. VATFlat rate to mainland UK and Northern Ireland (~0.00 kg). Channel Islands, Isle of Man, Republic of Ireland and international orders need a shipping quote.
Ordering 5+ units? Volume discounts available.
- 1-year manufacturer warranty
- Technical support: 01189 795319
Description
A Linear DC/DC converter with a regulated output and Maximum power of 27W with the input protected against reverse Polarity and the output with overvoltage protection. The converter is E and CE marked.
Product Specification
- Ce E Marked
- CE and E Marked
- Continuous Load Current
- 3A
- Electrical Separation
- No
- Input Terminals Conv
- 6.3mm Push on
- Input Voltage Conv Dc
- 12 VDC
- Input Voltage
- 10-16 VDC
- Maximum Power
- 27W
- Maximum Power Range
- 27W
- Model
- 9061
- MPN
- 9061120600
- Output Terminals
- 6.3mm Push on
- Output Voltage Text
- 6V DC
- Output Volt Conv Dc
- 6V DC
- Power Type
- Linear
- Regulated Output
- Regulated
- Weight
- 250g
Tested & certified to industry standards
